Goodman 1.5 Ton 16.2 SEER2 Heat Pump Inverter Side Discharge Condenser R32 GZV6SA1810
The Goodman GZV6SA1810 is a high-efficiency 1.5-ton side discharge heat pump condenser engineered for compact installations, quiet operation, and outstanding energy performance. Featuring a variable-speed inverter compressor and optimized for R-32 refrigerant, this unit delivers precise temperature control while meeting modern efficiency standards. With ENERGY STAR® certification, it is an ideal choice for homeowners seeking maximum efficiency in limited outdoor spaces.
Key Features
- Variable-Speed Inverter Compressor for Superior Comfort and Energy Savings
- Quiet Digitally Commutated Fan Motor
- High-Density Compressor Sound Blanket for Reduced Operating Noise
- Advanced Proprietary Control Algorithmic Logic
- Non-Communicating System Configuration
- Diagnostic Indicator Lights with Fault Code Storage
- AHRI Certified and ETL Listed
- Meets 2023 M1 Test Standards
- ENERGY STAR® Certified
Cabinet Features
- Heavy-Gauge Galvanized Steel Cabinet with Grille-Style Sound Control Side Design
- Custom Ivory White Powder-Paint Finish
- High-Corrosion ZAM® Unpainted Steel Bottom Frame and Legs
- 500-Hour Salt Spray Tested for Long-Term Corrosion Resistance
- Wire Fan Discharge Grille
- Top and Side Maintenance Access Panels
- Meets 2023 Florida Building Code Unit Integrity Requirements When Properly Anchored
This 1.5-ton condenser is ideal for smaller homes or zones requiring ultra-efficient performance, quiet operation, and compact side-discharge installation.
Goodman 96% 80K BTU Gas Furnace Variable Speed Upflow/Horizontal 17.5"W GRVT960803BN
The Goodman GRVT960803BN gas furnace delivers dependable, high-efficiency heating with advanced comfort features. With a 96% AFUE rating, two-stage gas valve, and variable-speed ECM blower motor, this furnace provides consistent warmth, improved indoor air comfort, and lower utility bills. Designed for small to medium-sized homes, it offers quiet operation and versatile installation options.
Key Features
-
80,000 BTU Input / 76,880 BTU Output – Efficient heating for reliable performance in residential spaces
-
96% AFUE Rating – Converts nearly all fuel into heat, significantly reducing energy costs
-
Two-Stage Gas Valve – Adjusts heating output to match demand for enhanced comfort and efficiency
-
Variable-Speed ECM Blower Motor – Ensures quieter operation and optimized airflow control
-
Condensing Furnace Design – Requires PVC or plastic flue venting for high-efficiency performance
-
Aluminized Steel Heat Exchanger – Built for long-term durability and heat transfer efficiency
-
Silicon Nitride Hot Surface Ignitor – Dependable ignition without the need for a standing pilot light
-
Heavy-Gauge Insulated Cabinet – Reduces air leakage, boosts thermal efficiency, and minimizes noise
-
Self-Diagnostic Control Board – Monitors system status and provides error codes for easy troubleshooting
-
ComfortNet Compatible – Enables advanced diagnostics, remote system monitoring, and fine-tuned control
-
Fuel Conversion Flexibility – Factory set for natural gas, easily convertible to propane with optional kit
-
Flexible Installation – Supports both upflow and horizontal configurations for adaptable setup
-
Warranty Coverage – Includes 10-year parts warranty and lifetime heat exchanger warranty with registration
Goodman 2 Ton Evaporator Coil 17.5" Cabinet EEV Expansion Upflow/Downflow CAPEA2418B3
The Goodman CAPEA2418B3 is a versatile cased evaporator coil engineered for both upflow and downflow installations. Designed for modern R-32 refrigerant systems, this indoor coil features a factory-installed Electronic Expansion Valve (EEV) for enhanced refrigerant control and compatibility with advanced communicating HVAC systems. With a compact 21" depth, it's ideal for tight attic spaces and applications requiring flexible installation without sacrificing performance or efficiency.
Product Features:
-
All-Aluminum Evaporator Coil – Built for durability and optimal heat transfer, reducing corrosion and increasing coil longevity.
-
R-32 Refrigerant Optimization – Engineered with specialized circuits and manifolds to maximize performance with environmentally friendly R-32 refrigerant.
-
Integrated R-32 Sensor – Designed to last the life of the coil and ensure optimal refrigerant management throughout system operation.
-
Factory-Installed Electronic Expansion Valve (EEV) – Provides precision refrigerant control and supports compatibility with Daikin One+ smart thermostats and Daikin communicating equipment.
-
Upflow & Downflow Configuration – Offers flexible installation options in a wide range of home HVAC setups.
-
Seven-Millimeter Coil Tubing – Improves overall system efficiency and performance in both cooling and heat pump applications.
-
Fault Recall Memory – Stores the six most recent system faults for simplified diagnostics and service.
-
Standardized Copper Suction Tube Stub Length – Ensures easier installation across different system configurations.
-
21-Inch Depth – Compact design allows for easier access during attic or tight-space installations.
-
Foil-Faced Internal Insulation – Helps reduce cabinet condensation, improves efficiency, and protects internal components.
-
Galvanized, Leather Grain-Embossed Finish – Rugged exterior provides lasting protection and resists wear and corrosion.
-
Rust-Resistant Thermoplastic Drain Pan – Low water-retention design helps prevent microbial growth and corrosion over time.
-
DecaBDE-Free, UV-Resistant Drain Pan – Environmentally conscious and built for long-term UV exposure without degradation.
-
Drain Pan Rails – Allow for easy removal and repositioning of the coil without compromising structural integrity.
-
AHRI Certified & ETL Listed – Meets strict efficiency and safety standards for trusted performance and compliance.
Advanced Control & Compatibility:
With its built-in electronic expansion valve (EEV), the CAPEA2418B3 supports advanced system communication and control, making it an ideal match for Daikin One+ smart thermostats and other Daikin communicating HVAC equipment. This advanced compatibility ensures better system performance, precision diagnostics, and maximum energy efficiency.
View More Heat Pump & Furnace Systems
Goodman 1.5 Ton 16.2 SEER2 Heat Pump Inverter Side Discharge Condenser R32 GZV6SA1810
| Brand |
Goodman |
SKU |
GZV6SA1810 |
| Tonnage |
1.5 Ton |
Heating Capacity |
18,000 BTU/H |
| Refrigerant Type |
R-32 |
SEER2 |
19 |
| Model Efficiency |
16.2 SEER2 |
Compressor Type |
Variable-Speed Inverter |
| Power Voltage |
208/230 V |
Power Phase |
1 Phase |
| Max Overcurrent Protection |
15 A |
Communication Type |
Non-Communicating |
| Unit Width |
36.625 in |
Unit Height |
27.375 in |
| Unit Depth |
13.75 in |
Unit Weight |
122 lb |
Goodman 96% 80K BTU Gas Furnace Variable Speed Upflow/Horizontal 17.5"W GRVT960803BN
| Brand |
Goodman |
SKU |
GRVT960803BN |
| BTU |
80,000 |
Weight |
120 lbs |
| Manufacturer |
Goodman |
Airflow Direction |
Upflow / Horizontal |
| Exhaust Flue Requirement |
Plastic / PVC |
Product Features |
New Refrigerant Compliant |
| Furnace Efficiency / AFUE |
96% |
Configuration |
Upflow / Horizontal |
| Energy Star |
Yes |
Burner Stages |
Two Stage |
| Fuel Type |
Propane, Natural Gas |
Height |
34 1/2" |
| Width |
17 1/2" |
Depth |
28 7/8" |
| Warranty |
Lifetime Heat Exchanger, 10 Years Unit Replacement, and 10 Years Parts with Online Registration |
Goodman 2 Ton Evaporator Coil 17.5" Cabinet EEV Expansion Upflow/Downflow CAPEA2418B3
| Brand |
Goodman |
SKU |
CAPEA2418B3 |
| Tonnage |
2 Ton |
Refrigerant |
R-32 |
| Valve |
Electronic Expansion Valve (EEV) |
Width |
17.5 inches |
| Coil Tubing |
7mm |
A2L Compatible |
Yes |
| Casing |
Cased |
Configuration |
Upflow/Downflow |
| Height |
18 inches |
Depth |
21 inches |
| Indoor/Outdoor |
Indoor |
Refrigeration Control Type |
EEV |
