Goodman 2 Ton 14.3 SEER2 Air Conditioner Condenser Single Stage R32 GLXS4MA2410
The Goodman GLXS4MA2410 2 Ton Air Conditioner Condenser is engineered for durability, energy efficiency, and compliance with the latest refrigerant standards. Designed for multi-family applications, this outdoor condensing unit utilizes environmentally friendly R32 refrigerant and a high-efficiency scroll compressor to deliver reliable cooling performance while meeting 2025 refrigerant guidelines.
Built with heavy-gauge galvanized steel and a powder-coated finish tested for 500-hour salt-spray durability, this unit is AHRI Certified, ETL Listed, and compliant with Florida Building Code wind-load requirements when properly installed. Ideal for residential and light commercial installations, the GLXS4MA2410 is a smart solution for energy-conscious builders and property owners.
Key Features
-
2 Ton Cooling Capacity – Designed for optimal performance in small to medium-sized multi-family dwellings
-
14.3 SEER2 Efficiency Rating – Offers improved seasonal energy efficiency and lower utility costs
-
R32 Refrigerant – Environmentally friendly refrigerant compliant with 2025 EPA regulations for reduced global warming potential
-
High-Efficiency Scroll Compressor – Delivers reliable, quiet performance with improved energy savings
-
Factory-Installed Filter Drier – Protects the refrigeration system from moisture and contaminants
-
Fully Charged for 15’ Line Set – Pre-charged with R32 refrigerant to simplify installation and reduce labor time
-
5mm Copper Tube / Enhanced Aluminum Fin Coil – Promotes superior heat transfer and long-term system durability
-
Service Valves with Sweat Connections – Easy-access gauge ports simplify maintenance and service tasks
-
High-Pressure Switch – Enhances safety by protecting against abnormal system pressure levels
-
Ground Lug Connection – Simplifies grounding during installation for added safety compliance
-
Enclosed Contactor – Helps prevent debris and moisture exposure for longer component life
-
Removable Grille-Style Top – Allows easy access for coil cleaning and is UL 60335-2-40 compliant
-
Venturi-Enhanced Airflow – Designed to increase airflow velocity and improve system efficiency
-
Architectural Gray Powder-Coated Finish – Weather-resistant finish tested for 500-hour salt spray exposure
-
Steel Louver Coil Guard – Protects the coil from debris and physical damage
-
Top and Side Maintenance Access – Simplifies service and diagnostics
-
Single-Panel Control Access – Includes space for field-installed accessories for flexible setup
-
Florida Building Code Compliant (2023) – Meets requirements for hurricane-type winds when properly anchored
-
AHRI Certified & ETL Listed – Verifies quality, performance, and regulatory compliance
Goodman 80% AFUE 60,000 BTU Gas Furnace 17.5" Wide Two Stage Upflow R32 GR9T800603BN
The Goodman 80% AFUE R32 2-Stage Gas Furnace delivers quiet, efficient heating with a 60,000 BTU output and advanced features designed for reliable, long-term performance. Ideal for residential applications, this furnace includes a two-stage gas valve and a multi-speed ECM blower motor to enhance comfort while minimizing energy consumption.
Equipped with a SureStart® Silicon Nitride igniter, self-diagnostic control board, and a two-speed induced draft blower, this furnace ensures smooth, quiet operation throughout the heating cycle. The fully insulated, heavy-gauge steel cabinet allows for multi-position installation, while compliance with California Low NOx standards ensures eco-conscious performance in approved areas.
Key Features
-
60,000 BTU Heating Capacity – Delivers consistent warmth for mid-sized residential spaces
-
80% AFUE Efficiency – Offers standard fuel efficiency for cost-effective heating
-
Two-Stage Gas Valve – Enhances comfort with quieter, more economical performance
-
Multi-Speed ECM Circulator Motor – Adjusts airflow as needed for efficiency and quieter operation
-
SureStart® Silicon Nitride Igniter – Engineered for long life and reliable ignition
-
Self-Diagnostic Control Board – Continuously monitors system performance and simplifies service
-
Low Constant Fan Speed – Provides quiet continuous air circulation for comfort and air quality
-
Quiet, Two-Speed Induced Draft Blower – Reduces startup and operating noise
-
California Low NOx Compliant – Meets emissions requirements (except for SCAQMD & SJVAPCD regions)
-
AHRI Certified & ETL Listed – Assures verified performance, safety, and regulatory compliance
Cabinet Features
-
Fully Insulated Heavy-Gauge Steel Cabinet – Reduces heat loss and operating noise
-
Durable Baked-Enamel Finish – Corrosion-resistant for long-term protection
-
Multi-Position Installation Options:
-
GR9T80: Upflow, horizontal left or right
-
GD9T80: Downflow, horizontal left or right
-
Removable Bottom Panel – Allows for bottom- or side-return air applications
-
Left or Right Gas/Electric Service Connections – Simplifies flexible installation
-
Cabinet Air Leakage: ≤ 2%
-
Flush Fit with Most Coils – Designed to match up seamlessly with Goodman evaporator coils
This Goodman 2-stage gas furnace provides efficient, dependable performance with smart features and a versatile cabinet design, making it a perfect choice for new HVAC installations or upgrades in homes outside of restricted California districts.
Goodman 2 Ton Cased Evaporator Coil 17.5"W Upflow/Downflow R32 With TXV CAPTA2422B3
The Goodman CAPTA2422B3 2 Ton Cased Evaporator Coil is engineered for long-lasting performance and optimal energy efficiency. Designed for both air conditioners and heat pump systems, this coil features an all-aluminum construction, factory-installed TXV, and a durable galvanized steel cabinet. Its compatibility with R-32 refrigerant and dual upflow/downflow orientation make it an ideal choice for residential and light commercial HVAC installations.
Built with reliability and efficiency in mind, the CAPTA Series coils are rigorously tested and backed by Goodman’s industry-leading warranty. Whether you're replacing an aging coil or designing a new system, the CAPTA2422B3 provides the flexibility, compatibility, and quality you can depend on.
Key Features
-
All-Aluminum Coil Design – Uses sine fins and grooved tubing to enhance heat transfer, reduce corrosion risk, and improve long-term durability
-
Factory-Installed Internal TXV – Provides precise refrigerant control and consistent performance in high-efficiency and variable-speed systems
-
Upflow/Downflow Installation Compatibility – Suitable for both upflow and downflow applications, simplifying system design and installation
-
Durable Galvanized Steel Cabinet – Embossed and insulated cabinet reduces air leakage and protects internal components
-
Advanced Condensate Management – Equipped with a UV-resistant, DecaBDE-free thermoplastic drain pan and foil-faced insulation to reduce moisture buildup
-
Double Pressure Tested at Factory – Each unit is pressure tested twice for maximum reliability and to prevent refrigerant leaks
-
R32 Refrigerant Compatible – Compliant with new Clean Air Act requirements and supports the transition to environmentally friendly cooling
-
10-Year Limited Parts Warranty – Backed by Goodman’s strong warranty coverage with registration and professional installation
Why Choose Goodman?
Goodman is a trusted leader in residential and light commercial HVAC systems across North America. Known for manufacturing high-performance products at an affordable price, Goodman is committed to delivering reliability, energy efficiency, and long-term value. When you choose a CAPTA Series evaporator coil, you're investing in quality components built to last.
