Goodman GD9T800603AX

Goodman R32 80% AFUE Gas Furnace 60K BTU 14"W Two-Stage Low NOx Downflow

By Goodman | Model: GD9T800603AX | ID: 100979
✓ Manufactured in the USA
✓ No Sales Tax - in most states excluding California
✓ Manufacturer Warranty Included
✓ Most Products In Stock - Call or Text (833) 658-3387 for availability
$1,381.00 + FREE SHIPPING

ADD TO CART FOR BEST PRICE
Product Details

Goodman R32 80% AFUE Gas Furnace 60K BTU 14"W Two-Stage Low NOx Downflow GD9T800603AX

The Goodman GD9T800603AX is a reliable 60,000 BTU gas furnace featuring a two-stage burner and a 9-speed ECM blower motor for precise and energy-efficient heating. Operating at 80% AFUE, this model delivers consistent performance with lower fuel usage and noise output. Designed for downflow or horizontal applications, the GD9T800603AX is California Low NOx compliant (except select counties) and can be converted to propane with an optional LP kit. It includes a durable hot surface igniter, self-diagnostic control board, and smart terminal connections for faster, simpler installations. This unit is ideal for heating small to medium-sized homes efficiently and quietly.

Key Features

  • 60,000 BTU heating input with 80% AFUE energy efficiency
  • Two-stage burner offers better comfort control and fuel savings
  • California Low NOx compliant (not Ultra-Low NOx)
  • 9-speed ECM blower motor ensures smart air circulation
  • Operates in downflow or horizontal configurations
  • Convertible to propane with optional LP kit
  • Metal flue venting required
  • Self-diagnostic control board improves serviceability
  • Durable hot surface igniter reduces maintenance needs
  • Designed for quick installation with universal layout and color-coded terminals

This model is a dependable, quiet, and efficient heating solution designed for flexible installation in basements, attics, or closets of small to medium-sized homes.

View More Furnaces

Specifications

Goodman R32 80% AFUE Gas Furnace 60K BTU 14"W Two-Stage Low NOx Downflow GD9T800603AX

Brand Goodman SKU GD9T800603AX
Type Gas Heat Category Gas Furnaces
Refrigerant Type R-32 Heating BTU 60,000
Temperature Rise Range (°F) 25-55 AHRI Certificate Number 215358012
Airflow Direction Downflow/Horizontal Exhaust Flue Requirement Metal
Brand/Manufacturer Goodman Product Features Low NOx, New Refrigerant Compliant
Furnace Efficiency / AFUE 80% Heating BTU 60,000
Blower Motor 9 Speed - ECM Maximum CFM 1200
Horsepower 1/2 HP Configuration Downflow/Horizontal
Electrical 115 V. 1 Phase 60 Hz Max Breaker Size 15 Amps
Min. Breaker Size 7.7 Amps Low NOx YES
NOx < 40 NG/J NOx Burner Stages Two Stage
Number of Burners 3 Fuel Type Propane, Natural Gas
Height 33 3/8" Width 14"
Depth 28" Shipping Weight (lbs) 107
UPC 633190210173 Type Counterflow Furnace
Warranty

Goodman R32 80% AFUE Gas Furnace 60K BTU 14"W Two-Stage Low NOx Downflow GD9T800603AX

Warranty Type Residential Multi-Family Commercial
Standard Warranty 5 year parts 5 year parts 5 year parts
Registered Warranty 10 year parts 10 year parts 5 year parts
Documents

Goodman R32 80% AFUE Gas Furnace 60K BTU 14"W Two-Stage Low NOx Downflow GD9T800603AX

GD9T80 Specification Sheets

GD9T80 Installation Manual

GD9T80 Warranty Information
