MRCOOL 12,000 BTU DIY Mini Split Heat Pump 5th Gen Easy Pro 115V 16ft Line Set

MRCOOL 12,000 BTU DIY Mini Split Heat Pump 5th Gen Easy Pro 115V 16ft Line Set

By MRCOOL | SKU: EZPRO-12-HP-11516D-O | ID: 040003
✓ No Sales Tax - in most states excluding California
✓ Manufacturer Warranty Included
✓ Satisfaction Guarantee - or return within 30 Days
✓ Most Products In Stock - Call or Text (833) 658-3387 for availability
$1,649.00 + FREE SHIPPING

ADD TO CART FOR BEST PRICE
Product Details

MRCOOL DIY EasyPro 5th Gen 12K BTU Ductless Mini Split Heat Pump System EZPRO-12-HP-11516D-O

The MRCOOL DIY EasyPro 5th Generation 12,000 BTU Ductless Mini Split Heat Pump System delivers powerful, energy-efficient heating and cooling for areas up to 550 sq. ft. With a design focused on DIY installation and smart control features, this system provides an ideal solution for homeowners seeking reliable year-round comfort without the cost of professional installation.

Key Product Features:

  • DIY-Friendly Installation
    - Includes a 16-foot pre-charged Fast Connection® line set for simple, tool-free setup
    - Perfect for homeowners looking to install their own mini split system
  • Smart Wi-Fi Control
    - Comes with SmartHVAC WiFi Control Module for remote operation via smartphone
    - Fully compatible with Amazon Alexa and Google Assistant for hands-free control
  • Energy-Efficient Performance
    - Achieves 19.5 SEER2 and 9.3 HSPF2-4 for year-round energy savings
    - Helps lower utility bills while maintaining consistent indoor temperatures
  • Ultra-Quiet Operation
    - Indoor unit runs as low as 17.5 dB(A) for whisper-quiet comfort
    - Ideal for bedrooms, living areas, and offices
  • Corrosion-Resistant Design
    - Equipped with Gold Fin® condenser coating for long-lasting durability
    - Excellent choice for coastal regions and high-humidity areas
  • Low Ambient Cooling
    - Operates in outdoor temperatures down to 5°F
    - Perfect for server rooms, greenhouses, and year-round cooling needs
  • Advanced Comfort Features
    - Includes Follow Me®, Sleep Mode, Auto Mode, Timer Mode, and refrigerant leak detection
    - Designed to enhance indoor comfort and operational safety

Specifications:

  • Cooling Capacity: 12,000 BTU
  • Heating Capacity: 12,000 BTU
  • SEER2: 19.5
  • HSPF2-4: 9.3
  • Voltage: 115V, 1 Phase, 60 Hz
  • Max Fuse Breaker: 20 A
  • Min Circuit Ampacity: 17 A
  • Refrigerant Type: R-454B
  • Refrigerant Volume: 32.10 oz
  • Indoor Noise Level: 17.5–44.5 dB(A)
  • Outdoor Noise Level: 54 dB(A)
  • Line Set Length: 16 ft (included), Max Length: 82 ft
  • Liquid Line Size: 1/4 in
  • Suction Line Size: 1/2 in
  • Compressor Type: Rotary
  • Indoor Unit Dimensions (W x D x H): 31.57 in x 7.87 in x 11.61 in
  • Indoor Unit Weight: 24.03 lbs
  • Outdoor Unit Dimensions (W x D x H): 28.35 in x 10.63 in x 19.49 in
  • Outdoor Unit Weight: 55.11 lbs

Warranty:

  • Parts Warranty: 2 Years
  • Compressor Warranty: 1 Year

The MRCOOL DIY EasyPro 5th Gen 12K BTU Ductless Mini Split System is an ideal solution for efficient and quiet home comfort. With smart features, simplified installation, and durable components, it’s perfect for homeowners who want to take control of their climate system with minimal hassle and maximum performance.

View More DIY Mini Split Systems

Specifications

MRCOOL EasyPro 5th Generation 12,000 BTU 115V Condenser EZPRO-12-HP-C-11516D-O

Brand MRCOOL SKU EZPRO-12-HP-C-11516D-O
Weight 54 Manufacturer MRCOOL
HSPF2 9.3 Cooling BTU 12,000 BTU
Heating BTU 12,000 BTU Refrigerant R454B
SEER2 19.5 Compressor Type Rotary
Liquid Line 1/4 Suction Line 3/8
Max Breaker Size 20 BTU/Tonnage 12,000 BTU/1 Ton
Zone Compatibility Single Zone Height 19.49
Width 28.35 Depth 10.63

MRCOOL EasyPro 5th Generation 12,000 BTU 115V Air Handler EZPRO-12-HP-WMAH-115D-O

Brand MRCOOL SKU EZPRO-12-HP-WMAH-115D-O
Weight 24 Manufacturer MRCOOL
Cooling BTU 12,000 BTU Heating BTU 12,000 BTU
Maximum CFM 353 Refrigerant R454B
Liquid Line 1/4 Suction Line 3/8
Max Breaker Size 15 BTU/Tonnage 12,000 BTU/1 Ton
Height 11.61 Width 31.57
Depth 7.87

Warranty

MRCOOL EasyPro 5th Generation 12,000 BTU 115V Condenser EZPRO-12-HP-C-11516D-O

Warranty Coverage
Parts 2 Years
Compressor 1 Year

MRCOOL EasyPro 5th Generation 12,000 BTU 115V Air Handler EZPRO-12-HP-WMAH-115D-O

Warranty Coverage
Parts 2 Years
Compressor 1 Year
Documents

MRCOOL EasyPro 5th Generation 12,000 BTU 115V Condenser EZPRO-12-HP-C-11516D-O

Brochure
Installation Manual
Warranty
AHRI Certificate
Energy Guide

MRCOOL EasyPro 5th Generation 12,000 BTU 115V Air Handler EZPRO-12-HP-WMAH-115D-O

Brochure
Installation Manual
Warranty
AHRI Certificate
Energy Guide

Shipping

We ship freight to the 48 contiguous states, excluding Hawaii and Alaska. Some shipping restrictions may apply. Liftgate services may incur an additional fee, which can be added at checkout.

Order Processing: Orders are processed within 1-3 business days (excluding weekends). Orders placed on Fridays will be processed the next business day. Once shipped, you’ll receive an email confirmation with tracking details. Backordered products may have longer processing times, and we will notify you of any delays.

Arrival of Goods: Freight delivery times depend on the carrier's schedule and routing. Estimated delivery times are provided at checkout. The carrier will contact you to arrange delivery, and you must be present to sign for the shipment.

Damages: Upon delivery, inspect your shipment carefully for any damage or discrepancies. Note any issues on the carrier’s delivery receipt and notify us within 24 hours. Claims made after this timeframe may be denied. Photographic proof is required for processing claims. Report damages or discrepancies immediately at support@hvacstore.com.

Returns: For returns unrelated to damage, contact us at support@hvacstore.com for authorization. Return shipping costs are the customer’s responsibility, and a 20% restocking fee applies. Items must be in original packaging and condition for a refund.

Delivery Receipt: Before signing the delivery receipt, inspect the shipment for any damage. Your signature confirms acceptance of the delivery unless issues are noted.

Policy Updates: Our shipping policy may change, and updates will be communicated via our website or other channels. For any questions, contact The HVAC Store at support@hvacstore.com or call (833) 658-3387.
