MRCOOL 24,000 BTU DIY Mini Split Heat Pump 5th Gen Easy Pro 230V 16ft Line Set

Name: MRCOOL 24,000 BTU DIY Mini Split Heat Pump 5th Gen Easy Pro 230V 16ft Line Set
Brand: MRCOOL
SKU: EZPRO-24-HP-23016D-O
Price: 2149.0 USD
Availability: InStock
Rating: 5 (6 reviews)

By MRCOOL | SKU: EZPRO-24-HP-23016D-O | ID: 040005

✓ No Sales Tax - in most states excluding California
✓ Manufacturer Warranty Included
✓ Satisfaction Guarantee - or return within 30 Days
✓ Most Products In Stock - Call or Text (833) 658-3387 for availability

$2,149.00 + FREE SHIPPING

ADD TO CART FOR BEST PRICE

Quantity

Product Details

MRCOOL EasyPro 5th Generation 24,000 BTU 230V Ductless Mini Split Heat Pump Complete System EZPRO-24-HP-23016D-O

The MRCOOL EasyPro 5th Generation 24,000 BTU 230V Ductless Mini Split Heat Pump Complete System is engineered to provide efficient heating and cooling for spaces up to 1,050 square feet. With a user-friendly DIY installation process, this system offers year-round comfort with exceptional energy efficiency, ensuring both savings and convenience.

Key Product Features:

DIY-Friendly Installation
- Includes a 16-foot pre-charged Fast Connection® line set for easy setup, eliminating the need for professional tools or training
- Ideal for homeowners looking for a hassle-free installation process
Smart Wi-Fi Control
- Compatible with the SmartHVAC Controller App, enabling remote operation from your smartphone
- Works with Amazon Alexa and Google Assistant for convenient voice control
Energy-Efficient Performance
- Achieves a SEER2 rating of 18.9 and an HSPF2-4 rating of 8.7, ensuring reliable performance with reduced energy costs
- Designed to provide comfort without compromising on energy savings
Quiet Operation
- Operates at a low noise level of 61 dB(A), making it suitable for bedrooms, offices, and other quiet spaces
- Perfect for maintaining peace and comfort in any environment
Durable and Corrosion-Resistant Design
- Features a Gold Fin® corrosion-resistant condenser for enhanced durability
- Ideal for coastal areas and regions with high humidity
Low Ambient Cooling
- Capable of cooling in outdoor temperatures as low as 5°F
- Perfect for server rooms, greenhouses, and other environments requiring continuous cooling
Advanced Comfort Features
- Includes Follow Me® function, Sleep Mode, Auto Mode, Timer Mode, and refrigerant leakage detection for enhanced safety and comfort
- Designed to optimize performance and provide consistent comfort

Specifications:

Cooling Capacity: 24,000 BTU
Heating Capacity: 25,000 BTU
SEER2: 18.9
HSPF2-4: 8.7
Voltage: 208/230V, 1 Phase, 60 Hz
Max Fuse Breaker: 20 A
Min Circuit Ampacity: 19 A
Refrigerant Type: R-454B
Refrigerant Volume: 34.92 oz
Noise Level: 61 dB(A)
Line Set Length: 16 ft (included), Max Length: 98.4 ft
Liquid Line Size: 1/4 in
Suction Line Size: 1/2 in
Compressor Type: Rotary
Indoor Unit Dimensions (W x D x H): 42.60 in x 9.21 in x 13.27 in
Indoor Unit Weight: 35.49 lbs
Outdoor Unit Dimensions (W x D x H): 35.04 in x 13.46 in x 26.50 in
Outdoor Unit Weight: 66.14 lbs

Warranty:

Parts Warranty: 2 Years
Compressor Warranty: 1 Year

The MRCOOL EasyPro 5th Generation 24,000 BTU 230V Ductless Mini Split Heat Pump Complete System is the ultimate solution for efficient and customizable heating and cooling. With DIY installation, smart controls, and advanced features, this system offers a perfect combination of performance, energy savings, and convenience.

View More DIY Mini Split Systems

Specifications

MRCOOL EasyPro 5th Generation 24,000 BTU 230V Condenser EZPRO-24-HP-C-23016D-O

Brand	MRCOOL	SKU	EZPRO-24-HP-C-23016D-O
Weight	95	Manufacturer	MRCOOL
HSPF2	8.7	Cooling BTU	24,000 BTU
Heating BTU	25,000 BTU	Refrigerant	R454B
SEER2	18.9	Compressor Type	Rotary
Liquid Line	3/8	Suction Line	5/8
Max Breaker Size	20	BTU/Tonnage	24,000 BTU/2 Ton
Zone Compatibility	Single Zone	Height	26.5
Width	35.04	Depth	13.46

MRCOOL EasyPro 5th Generation 24,000 BTU 230V Air Handler EZPRO-24-HP-WMAH-230D-O

Brand	MRCOOL	SKU	EZPRO-24-HP-WMAH-230D-O
Weight	35	Manufacturer	MRCOOL
Cooling BTU	24,000 BTU	Heating BTU	25,000 BTU
Maximum CFM	729	Refrigerant	R454B
Liquid Line	3/8	Suction Line	5/8
Max Breaker Size	15	BTU/Tonnage	24,000 BTU/2 Ton
Height	13.27	Width	42.6
Depth	9.21

Warranty

MRCOOL EasyPro 5th Generation 24,000 BTU 230V Condenser EZPRO-24-HP-C-23016D-O

Warranty	Coverage
Parts	2 Years
Compressor	1 Year

MRCOOL EasyPro 5th Generation 24,000 BTU 230V Air Handler EZPRO-24-HP-WMAH-230D-O

Warranty	Coverage
Parts	2 Years
Compressor	1 Year

Documents

MRCOOL EasyPro 5th Generation 24,000 BTU 230V Condenser EZPRO-24-HP-C-23016D-O

Brochure
Installation Manual
Warranty
AHRI Certificate
Energy Guide

MRCOOL EasyPro 5th Generation 24,000 BTU 230V Air Handler EZPRO-24-HP-WMAH-230D-O

Brochure
Installation Manual
Warranty
AHRI Certificate
Energy Guide
