Goodman 1.5 Ton R32 Split Air Conditioner Condenser 13.4 SEER2 Single Stage GLXS3BN1810
This energy-efficient compressor is designed for optimal performance and reliability. It comes fully charged for up to 15 feet of tubing length and features a robust copper tube with an enhanced aluminum fin coil, boasting a 5mm diameter for improved heat exchange. The unit includes a factory-installed filter drier, sweat connection service valves with convenient access to gauge ports, and an enclosed contactor for safety. Additionally, it is equipped with a high-pressure switch, a ground lug connection for secure grounding, and capacitors designed for extended life. The compressor is AHRI Certified and ETL Listed, ensuring adherence to industry standards for efficiency and safety.
Key Features
- New R32 Freon
- Removable grille-style top design, compliant with UL 60335-2-40
- Venturi for increased airflow velocity
- Attractive Architectural Gray powder-paint finish with 500-hour salt-spray approval
- Wire fan discharge grille
- Steel louver coil guard
- Top and side maintenance access
- Single-panel access to controls with space for field-installed accessories
- Meets 2023 Florida Building Code unit integrity requirements for hurricane-type winds when properly anchored
Goodman R32 80% AFUE Gas Furnace 60K BTU Two Stage Low NOx 17.5"W Upflow
The Goodman 80% AFUE R32 2-Stage Gas Furnace provides 60,000 BTU of efficient, quiet heating with a multi-speed ECM circulator motor and two-stage gas valve for optimal comfort. Equipped with a SureStart® Silicon Nitride igniter for long life, it operates smoothly with a low constant fan speed and quiet, two-speed draft blower. The furnace features a self-diagnostic control board, is AHRI Certified and ETL Listed for quality, and meets California Low NOx emissions standards. With flexible installation options and a durable, insulated cabinet, it ensures reliable home heating and easy setup.
In California, many counties have a lower NOx emission requirement than the rest of the United States. The GR9T800603BX Goodman gas furnace is California Low NOx compliant. With a built-in low emission filter, this Goodman gas furnace produces less nitrogen oxides to be released into the atmosphere, lowering the overall amount of toxic greenhouse gases output of the average California home.
Please note that this furnace cannot be installed in the following counties in California: Fresno, Joaquin, Kern, Kings, Los Angeles, Madera, Merced, Orange, Riverside, San Bernardino, San Stanislaus, and Tulare. In these counties you are required to purchase an Ultra-Low NOx furnace. If you have any questions, please contact us.
Product Features For Goodman 80% AFUE R32 2-Stage Gas Furnace
- NOx Burner Type: Low NOx
- Unit Height: 33-3/8 in
- Unit Width: 17.5 in
- AFUE: 80 %
- 60,000 BTU
- Installation Configuration: Upflow/Horizontal
- Max Overcurrent Protection: 15 A
- Power Phase: 1 Ph
- Power Voltage: 115 V
- Motor Speed Type: Multi Speed ECM
- Unit Weight: 107 lb
- Model Efficiency: 0.8
- Unit Depth: 28 in
- Heat Exchanger Type: Air Cooled
-
Two-stage gas valve provides quiet, economical heating
- Efficient and quiet multi-speed ECM circulator motor
-
SureStart® Silicon Nitride igniter designed for long igniter life
- Self-diagnostic control board
- Low constant fan speed circulates air throughout the home
- Quiet, two-speed induced draft blower
-
California Low NOx emissions-compliant models available
- Not for installation in California's South Coast Air Quality Management District (SCAQMD) and San Joaquin Valley Air Pollution Control District (SJVAPCD)
-
AHRI Certified and ETL Listed for quality assurance
Cabinet Features
- Fully insulated, heavy-gauge steel cabinet with durable baked-enamel finish
- Multi-position installation:
-
GR9T80: Upflow, horizontal left or right
-
GD9T80: Downflow, horizontal left or right
- Removable bottom for side- or bottom-return applications
- Convenient left or right gas/electric service connections
- Cabinet air leakage ≤ 2%
-
Coil and furnace fit flush for most installations
Goodman 2 Ton Evaporator Coil Cased With TXV 17.5" Height Horizontal CHPTA2426B3
The Goodman CHPTA2426B3 horizontal evaporator coil is engineered to provide efficient cooling and heating system performance when paired with a compatible condenser and furnace or air handler. Designed for horizontal installations, this coil features a factory-installed TXV valve, a mold-resistant drain pan, and durable aluminum construction. Its R32 refrigerant compatibility makes it a future-ready, environmentally responsible choice that complies with the Clean Air Act requirements.
Key Features
- 2-ton horizontal evaporator A-coil for AC or heat pump systems
- Factory-installed TXV for improved efficiency and refrigerant flow control
- R32 refrigerant compliant for enhanced environmental sustainability
- Durable galvanized, embossed cabinet with foil-faced insulation
- Thermoplastic, corrosion-resistant drain pan with antimicrobial protection
- Aluminum tube and fin coil for long-lasting performance
- Front-access split-seam panel for easier service and maintenance
- ETL Listed and AHRI Certified for quality and performance
