Goodman R32 96% AFUE Gas Furnace 40000 BTU Two Stage Downflow/Horizontal

Goodman R32 96% AFUE Gas Furnace 40000 BTU Two Stage Downflow/Horizontal

By Goodman | SKU: GD9T960403BN | ID: 100918
✓ Manufactured in the USA
✓ No Sales Tax - in most states excluding California
✓ Manufacturer Warranty Included
✓ Most Products In Stock - Call or Text (833) 658-3387 for availability
$2,066.00 + FREE SHIPPING

ADD TO CART FOR BEST PRICE
Product Details

Goodman R32 96% AFUE Gas Furnace 40000 BTU Two Stage Downflow/Horizontal

The Goodman Two-Stage R32 Gas Furnace GD9T960403BN delivers 40,000 BTU of reliable heating with an impressive 96% AFUE rating. Equipped with a multi-speed ECM blower motor and a two-stage gas valve, it offers quiet, efficient heating and optimal air circulation with 1200 CFM airflow. The heavy-duty aluminized-steel tubular heat exchanger, stainless-steel secondary heat exchanger, and durable silicon nitride igniter ensure longevity and reliable performance. Featuring self-diagnostic controls, low NOx compliance, and versatile installation options, this furnace is designed for efficient, long-lasting comfort. Not suitable for installation in certain California regions.

  • Unit Height: 34.5 in
  • Unit Width: 17.5 in
  • AFUE: 96 %
  • 40,000 BTU
  • 1200 CFM
  • Installation Configuration: Downflow/Horizontal
  • Max Overcurrent Protection: 15 A
  • Power Phase: 1 Ph
  • Power Voltage: 115 V
  • Motor Speed Type: Multi Speed ECM
  • Unit Weight: 112 lb
  • Model Efficiency: 0.96
  • Unit Depth: 28 in
  • Heat Exchanger Type: Air Cooled

Product Features For Goodman Two Stage R32 Gas Furnace GD9T960403BN

  • Energy-Efficient Multi-Speed ECM Blower Motor: Ensures optimal airflow and performance with reduced energy consumption.
  • Heavy-Duty Aluminized-Steel Tubular Heat Exchanger: Built for long-lasting durability and efficient heat transfer.
  • Stainless-Steel Secondary Heat Exchanger: Enhances heat transfer for improved heating efficiency.
  • Two-Stage Gas Valve: Provides quiet, economical heating for year-round comfort.
  • Durable Silicon Nitride Igniter: Ensures reliable operation and longevity of your system.
  • Quiet Two-Speed Induced Draft Blower: Reduces noise while maintaining efficient airflow.
  • Self-Diagnostic Control Board: Offers constant memory fault code history and LED output for easy troubleshooting.
  • Color-Coded Low-Voltage Terminals: Simplifies installation of electronic air cleaners and humidifiers.
  • Low Continuous Fan Speed: Ensures quiet air circulation, ideal for maintaining peace and comfort.
  • Complies with California’s 40 ng/J Low NOx Emissions Standard: Meets California’s strict air quality standards.
  • Not for Installations in SCAQMD & SJVAPCD: Excluded from California’s South Coast and San Joaquin Valley air districts.
  • AHRI Certified & ETL Listed: Verified for performance and safety by industry leaders.
  • Flexible Multi-Position Installation:
    • GR9T96: Upflow, horizontal left or right
    • GD9T96: Downflow, horizontal left or right
  • Direct Vent (2-Pipe) or Non-Direct Vent (1-Pipe) Certified: Provides installation flexibility for various venting setups.
  • Easy-to-Install Top Venting & Optional Side Venting: For GR9T96/upflow models, simplifying the venting process.
  • Left or Right Gas & Electrical Service Connections: Convenient and flexible installation options.
  • Cabinet Air Leakage (QLeak) ≤ 2%: Ensures energy efficiency and prevents heat loss.
  • Heavy-Gauge Steel Cabinet: Durable finish for long-term performance and protection.
  • Fully Insulated Heat Exchanger & Blower Section: Retains heat for better energy efficiency.
  • Airtight Solid Bottom or Side Return: Easy-to-remove tabs for quick installation in bottom air-inlet applications.

View More Furnaces

Specifications

Goodman R32 96% AFUE Gas Furnace 40000 BTU Two Stage Downflow/Horizontal

Brand Goodman SKU GD9T960403BN
Type Gas Heat Category Gas Furnaces
Refrigerant Type R-32 AHRI Certificate Number 215225019
Airflow Direction Downflow/Horizontal Exhaust Flue Requirement Plastic / PVC
Product Features New Refrigerant Compliant Furnace Efficiency / AFUE 96%
Heating BTU 40,000 High Fire Output 38,400
Blower Motor 9-Speed - ECM Maximum CFM 1200
Horsepower 1/2 HP Configuration Downflow/Horizontal
Energy Star Yes Electrical 115 V. 1 Phase 60 Hz
Max Breaker Size 15 Amps Min. Breaker Size 7.8 Amps
Burner Stages Two Fuel Type Propane, Natural Gas
Height 34.5" Width 17.5"
Depth 28.75" No. of Burners 2
Vent Diameter 2" - 3" Shipping Weight 112
UPC 633190210227
Warranty

Goodman R32 96% AFUE Gas Furnace 40000 BTU Two Stage Downflow/Horizontal

Warranty Type Residential Multi-Family Commercial
Standard Warranty 5 year parts 5 year parts 5 year parts
Registered Warranty 10 year parts 10 year parts 5 year parts
Documents

Goodman R32 96% AFUE Gas Furnace 40000 BTU Two Stage Downflow/Horizontal

GD9T96 Installation Manual

GD9T96 Specification Sheets

GD9T96 Parts Manual

GD9T96 Warranty Information
